Torque range

from 5.0 kNm up to 120.0 kNm

Applications
Wind turbines, coupling between engine and gear, industrial applications

The METAFLEX coupling is a torsionally stiff link style coupling. Due to the all-metal design the coupling is widely dirt and temperature resistant. The bending flexible link element of the coupling consists of layered rings which are made from stainless steel. The coupling is maintenance free. It is based on a modular system with a small number of individual components resulting in easy assembly and disassembly. Standard nominal torque rating is up to 120 kNm whereby the coupling features small diameter and low mass moments of inertia. Special designs, higher nominal torque capacities and higher permissible speeds are available on request.

SIZE>>>>>>>>NOMINAL TORQUE>>>>>>>>MAX TORQUE

W005R.....................5.00.......................................8.600
W008R.....................8.00.......................................15.000
W012R....................12.50......................................22.000
W020R.....................20.00......................................36.000
W031R....................31.50......................................58.000
W050R....................50.000.....................................86.000
W080R....................80.000.....................................150.000
W120R....................120.00.....................................220.000
