VULKAN HIGHLYFLEXIBLE COUPLINGS MEGIFLEX B

Harga :

CALL

Merk :

V U L K A N

Lokasi :

DKI Jakarta - Jakarta Timur

Dilihat :

309 Kali

Update Terakhir :

10-09-2016 22:34

Dapatkan Spesifikasi Harga VULKAN HIGHLYFLEXIBLE COUPLINGS MEGIFLEX B Produk Terbaik dari PT. DWISUBURMAKMUR Distributor Supplier Perangkat Industri, seperti Motor Industri, Pneumatic, Hydrolic, Sensor, Controller, PLC, Cluth, Brake, Reducer, Gear Box, dll.

Detail Produk

Torque range

0.010 kNm – 3.125 kNm

Applications
For flexibly and rigidly mounted diesel main propulsion and auxiliary drives in the low power range.

The MEGIFLEX B is a versatile, highly flexible coupling. With its modular design in combination with a compression-loaded element, the MEGIFLEX B complements the VULKAN product portfolio encompassing the torque range of small VULKARDAN E and VULASTIK L couplings. Due to its torsionally soft, shock-absorbing behaviour and high radial, axial and angular displacement capabilities the rubber element can meet a highly diverse range of requirements. Typical applications are in main propulsion; in particular with small pods, or auxiliary drives such as PTO/PTI with connected power units. The MEGIFLEX B is available in 15 sizes, each with 2 rubber stiffness classes, which can be either radially assembled or plugged in axially depending on the series. In addition to the compact design, the double cardanic MEGIFLEX B series is versatile as a highly displacing and torsionally flexible drive shaft for a broad range of Installation situations. The MEGIFLEX B is designed with an inbuilt fail-safe device.
SIZE & TORQUE
0421....10.00
0422.....12.50
0621.....20.00
0622.....25.00
0831.....40.00
0832.....50.00
1031.....80.00
1032.....100.00
1041.....120.00
1231.....160.00
1232.....200.00
1241.....220.00
1242.....275.00
1431....250.00
1432.....312.50
1441.....340.00
1442.....425.00
1631.....400.00
1632....500.00
1641.....600.00
1642.....750.00
1741......800.00
1742.....1000.00
2131.....900.00
2132.....1125.00
2142.....1750.00
2841......2500.00
2842.....3125.00

Hubungi :

PT DWI SUBUR MAKMUR

JL. Kayu Jati IV No 25

Jakarta Timur

Telp : 021 47869642, 47881968, 4759101,( 081292210171 )

FAX : 021 4719009

Email ; dsm@indo.net.id

===================

Torque range
0.010 kNm – 3.125 kNm

Applications
For flexibly and rigidly mounted diesel main propulsion and auxiliary drives in the low power range.

The MEGIFLEX B is a versatile, highly flexible coupling. With its modular design in combination with a compression-loaded element, the MEGIFLEX B complements the VULKAN product portfolio encompassing the torque range of small VULKARDAN E and VULASTIK L couplings. Due to its torsionally soft, shock-absorbing behaviour and high radial, axial and angular displacement capabilities the rubber element can meet a highly diverse range of requirements. Typical applications are in main propulsion; in particular with small pods, or auxiliary drives such as PTO/PTI with connected power units. The MEGIFLEX B is available in 15 sizes, each with 2 rubber stiffness classes, which can be either radially assembled or plugged in axially depending on the series. In addition to the compact design, the double cardanic MEGIFLEX B series is versatile as a highly displacing and torsionally flexible drive shaft for a broad range of Installation situations. The MEGIFLEX B is designed with an inbuilt fail-safe device.

SIZE & TORQUE
0421....10.00
0422.....12.50
0621.....20.00
0622.....25.00
0831.....40.00
0832.....50.00
1031.....80.00
1032....50.00
1031.....80.00
1032.....100.00
1041.....120.00
1231.....160.00
1232.....200.00
1241.....220.00
1242.....275.00
1431.....250.00
1432......312.50
1441......340.00
1442......425.00
1631......400.00
1632.....500.00
1641.....600.00
1642......750.00
1741......800.00
1742......1000.00
2131.......900.00
2141.......1400.00
2142.......1750.00
2841.......2500.00
2841......3125.00
