0.52 kNm - 52.00 kNm

Applications
Bell housing installation, rigid mounted engines

The VULASTIK L coupling is an axial pluggable highly flexible coupling developed for a variety of different applications. Four rubber qualities and silicone are available in order to tune the coupling to the various system requirements. VULASTIK L couplings are available with one elastic element in standard design or as dual execution with two parallel elements. The main parts of the VULASTIK L coupling are the hub and a flanged casing.Between these, the disc-shaped element is arranged. This disc element is vulcanized at its inner radius, the outer radius is connected to the flanged casing by a plug-in toothing. This toothing provides the axial plug-in feature and compensation of shaft displacements.
SIZE & TORQUE
X 1411....0.52
X 1412....0.65
X 1413....0.65
X 1418....0.65
X 1611....0.82
X 1612....1.04
X 1613....1.04
X 1618....1.04
X 1911....1.30
X 1912....1.63
