from 27,50 kNm up to 142,00 kNm

Applications
Generator sets on rigidly mounted engines, positioning drives

The RATO DG+ coupling has been specially designed for rigidly mounted diesel and gas engines and electric motors where a medium level of torsional flexibility and misalignment capacity is required. By virtue of its construction, it is also ideally suited for positioning drives, since it is supported vertically when installed upright. Like all newly developed ACOTEC products, the RATO DG+ is characterized by enhanced performance with regard to the essential technical specifications. The proven design principle of the standard RATO DG has been optimized yet again, and in conjunction with the innovative compound, vulcanization and test technology, it has undergone advanced development to obtain the enhanced performance DG+ design. In addition, the RATO DG+ has yet another significant commercial benefit since small size coupling may be used for the same power requirements.

SIZE......TORQUE
A 2K1S....27.50
A 2K1M....35.00
A 2K1H.....36.00
A 2KDS.....55.00
A 2KDM....70.00
A 2KDH....72.00
A 3DIS......44.00
A 3D1M....55.00
A 3D1H....56.00
A 3DDS...88.00
A 3DDM..110.00
A 3DDH....112.00
A 3E1S.....56.00
A 3E1M.....70.00
A 3E1H......71.00
A 3EDS.....112.00
A 3EDM.....140.00
A 3EDH.....142.00
