VULKAN CLUTCH MESLU

Harga :

CALL

Merk :

V U L K A N

Lokasi :

DKI Jakarta - Jakarta Timur

Dilihat :

180 Kali

Update Terakhir :

11-09-2016 10:42

Dapatkan Spesifikasi Harga VULKAN CLUTCH MESLU Produk Terbaik dari PT. DWISUBURMAKMUR Distributor Supplier Perangkat Industri, seperti Motor Industri, Pneumatic, Hydrolic, Sensor, Controller, PLC, Cluth, Brake, Reducer, Gear Box, dll.

Detail Produk

Torque range

8.0 kNm - 315.0 kNm

Applications
Specific data on request only

The VULKAN MESLU clutch is a pneumatically operated double-cone friction clutch for dry running. It is backlash-free, possesses no rubbing surfaces in its internal construction that could be subject to wear and tear, and thanks to the external friction sheaths, features high maximum shifting and good heat radiating capacity. The clutch produces no axial load, either when engaged or disengaged. Through the arrangement of the double-cone an automatic adjustment is afforded during gradual wear of the friction linings. The friction lining is subject to natural wear and tear. The linings, made from high-performance friction material based on asbestos-free synthetic resin, are safely dimensioned and extremely wear-resistant, so that several years of operation is ensured even with frequent shifting.
COMBINATION ->>>>>>>>>SIZE CLUTCH....SIZE COUPLING
MESLU-VULKARDAN E >>>>>MESLU 19>>>>>>5412
MESLU-VULKARDAN E>>>>>MESLU 20 >>>>> 5415
MESLU- VULKARDAN E >>>>MESLU 21>>>>>5711
MESLU- VULKARDAN E>>>>>MESLU 22>>>>>>5714
MESLU- VULKARDAN E>>>>>MESLU 23>>>>>>5712
MESLU- VULKARDAN E >>>>MESLU 24>>>>>5715
MESLU- VULKARDAN E >>>>MESLU 24>>>>>6011
MESLU- VULKARDAN E >>>>MESLU 25>>>>>6014
MESLU- VULKARDAN E >>>>MESLU 26.>>>>>6012
MESLU- VULKARDAN E >>>>MESLU 27 >>>>>6015
MESLU-RATO R+ >>>>>>>>>MESLU 45>>>>>G2D2S
MESLU-RATO R+ >>>>>>>>>MESLU 46>>>>>G2D2M
MESLU-RATO R+ >>>>>>>>>MESLU 47>>>>>G2D2H
MESLU- RATO R+ >>>>>>>>>MESLU58>>>>>G2F2H
MESLU- RATO R+ >>>>>>>>>MESLU59>>>>>G2G2M
MESLU- RATO R+ >>>>>>>>>MESLU90>>>>>G2G2H
MESLU- RATO R+ >>>>>>>>> MESLU91>>>>>G3B2S
MESLU- RATO R+>>>>>>>>>>MESLU 145>>>>G3B2H
MESLU- RATO R+>>>>>>>>>>MESLU 146>>>>G3C1H
MESLU- RATO R+>>>>>>>>>>MESLU 147>>>>G4A1S
MESLU- RATO R+>>>>>>>>>>MESLU 225>>>>G4A1H
MESLU- RATO R+>>>>>>>>>> MESLU 330>>>>G471ZR
MESLU- RATO R+>>>>>>>>>>MESLU 330>>>>>G471TR
MESLU- RATO S+>>>>>>>>>>MESLU 420>>>>>G5G2M
MESLU- RATO S+>>>>>>>>>>MESLU 420<<<<<G5G2H
