VOITH Highly Flexible D Coupling Series BR 1xx

Harga :

CALL

Merk :

V O I T H T U R B O

Pengiriman :

3 hari sejak pembayaran

Lokasi :

DKI Jakarta - Jakarta Timur

Dilihat :

176 Kali

Update Terakhir :

24-09-2016 22:26

Dapatkan Spesifikasi Harga VOITH Highly Flexible D Coupling Series BR 1xx Produk Terbaik dari PT. DWISUBURMAKMUR Distributor Supplier Perangkat Industri, seperti Motor Industri, Pneumatic, Hydrolic, Sensor, Controller, PLC, Cluth, Brake, Reducer, Gear Box, dll.

Detail Produk

Highly flexible D couplings are especially well-suited for engine test rigs for testing 1‑ to 3-cylinder internal combustion engines. D couplings feature a high torsional flexibility and high torque capacity. Development test rigs, continuous-running test rigs, and end-of-line test rigs operate safely and reliably with this coupling at speeds of up to 10 000 rpm.

D couplings shift a system's critical resonance frequencies below the operational speed range. In addition, the couplings dampen undesirable alternating torques. This increases the service life of all the test rig drive components. Your test rig operates with a high level of availability.

The D coupling's modular design enables very flexible integration into a wide variety of engine test rigs. We adapt the length of the coupling, connections, and torsional rigidity to your test rig.

BR 191:
Coupling shafts with length compensation (slip)

Features:

Torque rating T_KN:
140 – 700 Nm
Connection engine flywheel – flange
Especially suitable for engine test rigs

BR 191:
Coupling shafts with length compensation (slip)

Features:

Torque rating T_KN:
140 – 700 Nm
Connection engine flywheel – flange
Especially suitable for engine test rigs
