VOITH BHS ROTOR TURNING GEAR UNITS
Merk :
V O I T H T U R B O
Pengiriman :
3 hari sejak pembayaran
Lokasi :
DKI Jakarta - Jakarta Timur
Update Terakhir :
25-09-2016 18:51
Dapatkan Spesifikasi Harga
VOITH BHS ROTOR TURNING GEAR UNITS Produk Terbaik dari
PT. DWISUBURMAKMUR Distributor Supplier Perangkat Industri, seperti Motor Industri, Pneumatic, Hydrolic, Sensor, Controller, PLC, Cluth, Brake, Reducer, Gear Box, dll.
Detail Produk
BHS rotor turning gear units primarily provide safe cooling for hot rotors in a steam or gas turbine or compressor by slow turning. This helps the rotor remain dimensionally stable. Rotor turning gear units also provide for breakaway, startup, or precisive positioning of shaft trains.
Voith offers solutions for free and connected shaft ends that cover requirements from 0.2 to 500 rpm and breakaway torques of up to 100 000 Nm.
Customers value the rotor turning gear in a package with a BHS turbo gear unit in case of a free available shaft end.
Voith's more than 40 years of experience in designing rotor turning gear units and more than 2 000 references confirm the reliability and safety of BHS rotor turning gear units.
Technical data
| Motor power |
0.75 – 200 kW |
| Speeds |
from 0.2 to 500 rpm |
Breakaway torque and mass
moments of inertia |
300 to 100 000 Nm
| Special designs |
- with hydraulic motor
- with return stop
- with hydraulically triggered overload coupling
- with switched overrunning clutch (lockout)
|
| Delivery options |
- Control cabinets
- Attachments:
- adapter flanges
- gear rims
- soft starters
|
up to 100 000 kg m² |
| Design models |
- with overrunning clutch
- with swivel pinion
|
| Meets the following standards |
ATEX |
