The magnet ring encoder is the ideal product to measure rotational speed of large shafts in rough conditions. Because of the segmented ring into peaces, the installation, service and transport is much easier than within other solutions.
| Technical data | |
|---|---|
| Shaft type | - Inner ring diameter between 1mm and more than 2000mm - Outer ring diameter >140mm |
| Flange type | - Flange mount for fixing to a flange expansion or - ClampFit for mounting without flange expansion |
| Resolution | Free of choice |
| Output signal | HTL, HC-HTL, TTL, RS-422, Optolink |
| Connection | M23, cable |
| Protection class | IP 67 (acc. to IEC 60529) |
| Temperature range | -40°...+80°C |
| Special feature | Wide range air gap and tolerances between sensor head and magnet ring: - radial 0.1mm - 2.6mm - axial +/- 4mm |
