This coupling is particularly suitable if overload protection and vibration damping are required. They protect your drive equipment and increase the productivity of your system.
This fluid coupling is also available with two work circuits (type DT). The parallel acting circuits double the power transmission.
We offer fluid couplings with water as the operating medium (type TW) especially for potentially explosive atmospheres or with outer casing made of spheroidal cast iron (type TU) for use in operations with relevant material requirements.
Temperature monitoring systems (MTS, BTS, BTM) increase the availability of the drive and boost the productivity of the system.
Coupling Name .... Coupling Type
T..............Constant Fill , Basic Version
TV............Constant Fill , Coupling With delay chamber
TVV..........Constant Fill , Coupling with enlarged delay chamber
TVS..........Constant Fill , Coupling with enlarged delay chamber and annular chamber shell
TVVS.........Constant Fill, Coupling With centrifugal Force valves
TV...F.......Constant Fill, Coupling with centrifugal force valves
TV...Y........Constant Fill, Refilling holes between working space and delay chamber
TP..............Fill-Controlled Bearing supported ,separate oil sytem wilh valces and active cooling
TPK...........Fill-Controlled Bearing supported , separate oil sytem with valves and active cooling
TPW...........FILL-Controlled Special solution without housing
TPKL.........FiILL-Controlled Integral bearing , with oil tank , valves and active
Turbo Belt
780 TPXL...Fill-Controlled Turnel version , sensor and actuator are intrinsicaly safe
DTPKWL2. Fill-Controlled Tunnel Version , sensors and actuators are intrinsically safe, with XL Shape for higher power transmission
CPC...........FILL-Controlled.....Tunner Version , sensor and Actuators are intrinsically safe.....
TD............. Constant Fill for diesel Engines ...... Basic Version
TPKD-SAE...Fill-Controlled , For diesel Engines
