The ELPEX coupling is suitable for horizontal and vertical mounting positions or mounting at any required angle. The coupling parts can be arranged as required on the shafts to be connected. The split flexible rings can be changed without having to move the coupled machines. The flexible rings are mounted without backlash and give the coupling progressive torsional stiffness, i.e. torsional stiffness increases in proportion to coupling load. The ELPEX coupling is especially suitable for reversing operation or operation with changing directions of load. The coupling is delivered preassembled. The flexible rings are completely assembled. On the type ENG, the coupling halves have to be bolted together after the hub has been mounted. On the type EFG, after mounting the coupling hub, only the outer flange has to be connected to the machine. Outer flanges with different connection dimensions are available for the type EFG. If the flexible rings are irreparably damaged or worn, the metal parts can rotate freely against one another, they are not in contact with one another.
T Y P E :
Type ENG/ENGS : Coupling as shaft / coupling as flange
Type ENGS/EFGS : as with fail - safe device
SIZE :
270, 320, 375, 430, 500, 590, 690, 840, 970.
