The ELPEX-S coupling is suitable for horizontal and vertical mounting positions or mounting at any required angle. The coupling parts can be arranged as required on the shafts to be connected. ELPEX-S couplings are especially suitable for reversing operation or operation with changing directions of load. The rubber disk elements are fitted virtually without backlash and give the coupling linear torsional stiffness, i.e. the torsion stiffness remains constant even when the load on the coupling increases. There are 4 different rubber element versions with different grades of torsional stiffness available for each size from stock. On certain types the flexible rings can be changed without having to move the coupled machines. If substantial overload occurs, the rubber disk element of the coupling is irreparably damaged, the coupling throws the load and thus limits the overload for particular operating conditions. The coupling can be inserted and fitted blind e.g. in a bell housing. There are outer flanges with different connection dimensions available for each coupling size.
T Y P E :
T Y P E : ESN
T Y P E : ESD
T Y P E : ESNR
T Y P E : ESDR
T Y P E : ESDR
Technical data :
T Y P E ESN/EST : Size 220, 260, 265, 290, 320, 360, 420,460 .
T Y P E ESN : Size 520,560, 580, 680, 770,
T Y P E ESD : Size 520, 560, 580, 680, 770.
Hubungi :
PT DWI SUBUR MAKMUR
JL. Kayu Jati IV No 25
Jakarta Timur
Telp : 021 47869642, 47881968, 4759101,( 081292210171 )
FAX : 021 4719009
Email ; dsm@indo.net.id
===================
